MPO 48 Fiber OM3 and OM4, 50/125 Multimode Assemblies



MPO Trunk OM3 and OM4 Indoor Configurations
Pinout DesignFiberdyne ConfigurationDescription
Type A Polarity38 MPO-MPO,
Two 24 Position 20 Fiber to Two 24 Position 20 Fiber
Type B Polarity42 MPO-MPO,
Four 12 Position 10 Fiber to Four 12 Position 10 Fiber
Type C Polarity44 MPO-MPO,
Four 12 Position 10 Fiber to Four 12 Position 10 Fiber
Type A Polarity48 MPO-MPO,
Four 12 Position 12 Fiber to Four 12 Position 12 Fiber
Type B Polarity53 MPO-MPO,
Four 12 Position 8 Fiber to Four 12 Position 8 Fiber
Type A Polarity58 MPO-MPO,
Four 12 Position 12 Fiber to Four 12 Position 12 Fiber
Type C Polarity63 MPO-MPO,
Four 12 Position 12 Fiber to Four 12 Position 12 Fiber



MPO-LC Trunk OM3 and OM4 2mm Breakout Indoor Configurations
Pinout DesignFiberdyne ConfigurationDescription
Type A Polarity66 MPO-LC,
Two 24 Position 20 Fiber MPO to Two Groups of 20 LC
2mm Breakout
Type A Polarity90 MPO-LC,
Four 12 Position 8 Fiber MPO to Four Groups of 8 LC
2mm Breakout
Type A Polarity105 MPO-LC,
Four 12 Position 12 Fiber MPO to Four Groups of 12 LC
2mm Breakout
Type C Polarity120 MPO-LC,
Four 12 Position 12 Fiber MPO to Four Groups of 12 LC
2mm Breakout



New York



MPO-SC Trunk OM3 and OM4 2mm Breakout Indoor Configurations
Pinout DesignFiberdyne ConfigurationDescription
Type A Polarity74 MPO-SC,
Two 24 Position 20 Fiber MPO to Two Groups of 20 SC
2mm Breakout
Type A Polarity100 MPO-SC,
Four 12 Position 8 Fiber MPO to Four Groups of 8 SC
2mm Breakout
Type A Polarity115 MPO-SC,
Four 12 Position 12 Fiber MPO to Four Groups of 12 SC
2mm Breakout
Type C Polarity130 MPO-SC,
Four 12 Position 12 Fiber MPO to Four Groups of 12 SC
2mm Breakout
