Fiberdyne Labs Configuration 25 MPO-LC, 24 Pin 20 Fiber to 20 LC (In Clipped Pairs), 100GBase-SR10, Option A, 2mm Breakout
Configuration 25 MPO-LC, 24 Pin 20 Fiber to 20 LC (In Clipped Pairs), 100GBase-SR10, Option A, 2mm Breakout
Back to 100G Assemblies Page
| View PDF Version |
| Note: Configurations illustrated below indicate an alignment pin option of No Pin to No Pin (NP-NP). If other alignment pinning is required, see part number matrix in the drawing. Prices are the same regardless of pinning. |
|
|
Fiberdyne Labs, Inc.
127 Business Park Drive, Frankfort, New York
Toll Free: 800-894-9694
Phone: 315-895-8470
Fax: 315-895-8436
Email:
Fiberdyne Labs manufactures MPOs in a variety of configurations.
Call your Fiberdyne Sales Representative at 800-894-9694 or email us at
