Fiberdyne Labs, Inc. 50/125 OM2 6 Pack, Assemblies, 900um Pigtail

50/125 OM2 6 Pack, Color Coded Assemblies, 900um Pigtail


2 & 3mm cables available



Technical Date Sheet Technical Date Sheet



Specifications:
Cable & Connector Specifications:
Fiber Type 50/125 OM2 Multimode
Insertion Loss Per Connector
< 0.3dB, Typical 0.25dB
Return Loss VS. Polish TypeUPC: > 50dB, Typical 55dB
APC: > 60dB, Typical 65dB
Apex Offset< 50µm
Fiber Height< 100nm
Repeatability> 500 Cycles
Operating Temperature-40°C To +75°C
Humidity Range5% To 95% (Non-Condensing)
Strain Relief Boot Lengths2.2cm to 3.5cm Available



50/125 OM2 6 Pack Color Coded 900µm Pigtail Assemblies
LC-Pigtail 6 Pack F9G1BC4GCL0XXXM6PSpecify Length When Ordering
SC-Pigtail 6 Pack F9G1BC4GC60XXXM6PSpecify Length When Ordering
ST-Pigtail 6 Pack F9G1BC4GC10XXXM6PSpecify Length When Ordering
FC-Pigtail 6 Pack F9G1BC4GC70XXXM6PSpecify Length When Ordering

Other Connector Combinations available.

New York

Fiberdyne Labs manufactures Singlemode & Multimode Assemblies in a variety of configurations.
